Applications
Description
Polyester Film, also known as PET or Mylar has good transparency, high machinability, sparkling gloss, flexibility and excellent resistance against water vapor and chemicals.
Corrugated Polyester Film can enhance the tightness of cable wrapping.
Characteristics
• Good insulation and economical cost
• High mechanical strength, tensile and wear resistance
• Wrapping tighter and firmer
| Code List No. |
Thickness um |
Density g/cc |
Tensile MPa |
Elongation % |
Hotmelt Point ℃ |
Breakdown Voltage KV |
| 10200-CP035 | 35±10% | 1.40±0.05 | >100 | >90 | 225-240 | >5 |
| 10200-CP050 | 50±10% | 1.40±0.05 | >120 | >100 | 225-240 | >6 |
| 10200-CP075 | 75±10% | 1.40±0.05 | >120 | >100 | 225-240 | >7 |
*Corrugation Thickness: 0.15-0.2um Corrugation Direction: Longitudinal
Above characteristics can be changed to meet the specific requirements of customers.
Package
1. Width, Length, Color, ID and OD… All can be adjusted according to the customer request.
2. Jumbo Roll, Slit Pad, Traverse Spool… Package are available upon request.
